B380C1500A | Diotec
Diotec bridge rectifier, 380 V, 800 V (RRM), 2.3 A, SIL, B380C1500A
Unit Price (€ / pc.)
3.0821 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
3.08 € *
Price list
Quantity
Price per unit*
1 pcs.
3.0821 €
10 pcs.
2.5823 €
100 pcs.
2.2015 €
250 pcs.
1.9873 €
*incl. VAT plus shipping costs
Subject to prior sale
Bridge rectifier, B380C1500A, DIOTEC
Features
- For free-standing or heatsink assembly
- UL recognized
- Compliant to RoHS, REACH and conflict minerals
Applications
- 50/60 Hz mains rectification
- Power supplies
- Commercial grade
Technical specifications
| Version | 1-phase | |
| Assembly | THT | |
| Enclosure | SIL | |
| Input voltage | 380 V | |
| Rated current | 2.3 A | |
| Voltage V RRM (peak reverse voltage) | 800 V | |
| min. operating temperature | -50 °C | |
| max. operating temperature | 150 °C |
Download
Logistics
| Customs tariff number | 85411000 |
| Country of origin | SI |
Compliance
| SVHC free | No |
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
