ESD05B1Z | Diotec Semiconductors
SMD ESD protection diode, bidirectional, 170 W, 5 V, 0603, Diotec Semiconductors ESD05B1Z
Order No.: 70S0068
MPN:
ESD05B1Z
Unit Price (€ / pc.)
0.1321 € *
Standard delivery time from the manufacturer is: 10 Weeks
Total Price:
1.32 € *
Price list
Quantity
Price per unit*
10 pcs.
0.1321 €
100 pcs.
0.0821 €
250 pcs.
0.0500 €
1000 pcs.
0.0333 €
10000 pcs.
0.0262 €
*incl. VAT plus shipping costs
Subject to prior sale
ESD Protection Diode in SMD, ESD05B1Z, Diotec
Features
- Low junction capacitance
- Low leakage current
- Miniature case outline outline
Applications
- ESD protection
- Data line and I/O port protection
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | bidirectional | |
| Pulse power loss | 170 W | |
| Rated blocking voltage | 5 V | |
| Breakdown voltage | 8 V | |
| min. operating temperature | -50 °C | |
| max. operating temperature | 150 °C | |
| Assembly | SMD | |
| Enclosure | 0603 |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Reel with 10,000 pieces |
| Customs tariff number | 85411000 |
| Country of origin | CN |
| MSL | MSL 1 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
