DI056N10D2 | Diotec Semiconductors

Diotec Semiconductors N channel MOSFET, 100 V, 56 A, D2PAK, DI056N10D2

Order No.: 09S6130
MPN:
DI056N10D2
Diotec Semiconductors
DI056N10D2 Diotec Semiconductors MOSFETs
Image may differ
Print
Key Specification:
Version N channel
max. Voltage 100 V
Max. current 56 A
drain-source on resistance RDS (on) max @VGS=4,5V 13 mΩ
drain-source on resistance RDS (on) max @VGS=10V 9.5 mΩ
Show variants: 2
Download Datasheet Technical specifications
Unit Price (€ / pc.)
0.7616 € *
Standard delivery time from the manufacturer is: 10 Weeks
Total Price:
609.28 € *
*incl. VAT plus shipping costs
Subject to prior sale
800 pcs.
0.7616 €
Description
Technical specifications
Download
Logistics
Compliance
Variations

SMD Small Signal Diode, DI056N10D2, Diotec Semiconductors

Features

  • Very high switching speed
  • Low junction capacitance
  • Low leakage current

Applications

  • Signal processing
  • High-speed switching
  • Rectifying
Technical specifications
Version N channel
max. Voltage 100 V
Max. current 56 A
drain-source on resistance RDS (on) max @VGS=4,5V 13 mΩ
drain-source on resistance RDS (on) max @VGS=10V 9.5 mΩ
Enclosure D2PAK
Gate Charge Qg @10V (nC) 3.8x10<sup>-8</sup> C
Power loss 57.6 W
Assembly SMD
min. operating temperature -55 °C
max. operating temperature 150 °C
Articles of same specification 0
Logistics
MSL MSL 1
Customs tariff number 85412900
Country of origin CN
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
