DIJ015M065 | Diotec Semiconductors
IGBT, 650 V, 15 A, TO-247, Diotec Semiconductors DIJ015M065
Order No.: 70S0380
MPN:
DIJ015M065
Unit Price (€ / pc.)
0.8330 € *
Standard delivery time from the manufacturer is: 10 Weeks
Total Price:
0.83 € *
Price list
Quantity
Price per unit*
1 pcs.
0.8330 €
100 pcs.
0.6664 €
250 pcs.
0.6069 €
500 pcs.
0.5355 €
1000 pcs.
0.4879 €
*incl. VAT plus shipping costs
Subject to prior sale
Medium Fast Switching IGBT with Reverse Diode, DIJ015M065, Diotec
Features
- Trench & Fieldstop Technology
- Low saturation voltage
- Medium switching speed
- Parallel operation possible
- Short circuit proof
- Compliant to RoHS
Applications
- Switching frequency 40-60 kHz
- Solar inverters
- PTC Heaters
- Uninterruptiple Power Supplies (UPS)
- Commercial / Industrial grade
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | single | |
| Power dissipation | 39 W | |
| Assembly | THT | |
| min. operating temperature | -55 °C | |
| Switching loss at switch-on Eon typ. | 0.3 J | |
| max. Voltage | 650 V | |
| Max. current | 15 A | |
| Saturation voltage | 1.6 V | |
| Enclosure | TO-247 | |
| max. operating temperature | 150 °C | |
| Switching loss b. switch off Eoff typ. | 0.27 J |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85412900 |
| Original Packaging | Bar with 50 pieces |
Compliance
| Property | Value |
|---|---|
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
