B500C3700-2200A | Diotec Semiconductor
Diotec Semiconductor bridge rectifier, 500 V, 1 kV (RRM), 3.7 A, SIL, B500C3700-2200A
This item is no longer available.
As an alternative, we recommend the following item:
Diotec Semiconductor bridge rectifier, 700 V, 1 kV (RRM), 20 A, SIL, GBI20M
Order No.: 09S4161
Manufacturer: Diotec Semiconductor
per pc. 0.6664 € *
Silicon-Bridge-Rectifier, B500C3700-2200A, DIOTEC
Features
- Four diodes in bridge configuration
- For free-standing or heatsink assembly
- UL recognized
Applications
- 50/60 Hz mains rectification
- Power supplies
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | 1-phase | |
| Assembly | THT | |
| Enclosure | SIL | |
| Input voltage | 500 V | |
| Rated current | 3.7 A | |
| Voltage V RRM (peak reverse voltage) | 1 kV | |
| min. operating temperature | -50 °C | |
| max. operating temperature | 150 °C |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | IN |
| Customs tariff number | 85411000 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
