B40C5000-3300A | Diotec Semiconductor
Diotec Semiconductor bridge rectifier, 40 V, 80 V (RRM), 5 A, SIL, B40C5000-3300A
This item is no longer available.
As an alternative, we recommend the following item:
Diotec Semiconductor bridge rectifier, 70 V, 100 V (RRM), 20 A, SIL, GBI20B
Order No.: 09S4156
Manufacturer: Diotec Semiconductor
per pc. 0.6664 € *
Diode bridge rectifier, B40C5000-3300A, DIOTEC
Features
- Four diodes in bridge configuration
- For free-standing or heatsink assembly
- UL recognized
- Compliant to RoHS, REACH and conflict minerals
Applications
- 50/60 Hz mains rectification
- Power supplies
- Commercial grade
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | 1-phase | |
| Assembly | THT | |
| Enclosure | SIL | |
| Input voltage | 40 V | |
| Rated current | 5 A | |
| Voltage V RRM (peak reverse voltage) | 80 V | |
| min. operating temperature | -50 °C | |
| max. operating temperature | 150 °C |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85411000 |
| Country of origin | IN |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
