B40C1500A | Diotec Semiconductor

Diotec Semiconductor bridge rectifier, 40 V, 80 V (RRM), 2.3 A, SIL, 19 x 10 x 3.5, B40C1500A

Order No.: 60A650
EAN: 4099879038357
MPN:
B40C1500A
Series: B..C
Diotec Semiconductor
B40C1500A Diotec Semiconductor Bridge Rectifiers
Image may differ
Print
Key Specification:
Version 1-phase
Assembly THT
Enclosure SIL, 19 x 10 x 3.5
Input voltage 40 V
Rated current 2.3 A
Show variants: 6
Download Datasheet Technical specifications
This item is no longer available.
As an alternative, we recommend the following item:
Diotec Semiconductor bridge rectifier, 140 V, 200 V (RRM), 3 A, SIL, KBP302G
Diotec Semiconductor bridge rectifier, 140 V, 200 V (RRM), 3 A, SIL, KBP302G
Order No.: 62A298
Manufacturer: Diotec Semiconductor
per pc. 0.2892 € *
Go to product
*incl. VAT plus shipping costs
Description
Technical specifications
Download
Logistics
Compliance
Replacement
Variations

Single Phase Bridge Rectifier, B40C1500A, DIOTEC

Features

  • For free-standing or heatsink assembly
  • UL recognized

Applications

  • 50/60 Hz mains rectification
  • Power supplies


Technical specifications
Version 1-phase
Assembly THT
Enclosure SIL, 19 x 10 x 3.5
Input voltage 40 V
Rated current 2.3 A
Voltage V RRM (peak reverse voltage) 80 V
min. operating temperature -50 °C
max. operating temperature 150 °C
Articles of same specification 0
Logistics
Country of origin IN
Customs tariff number 85411000
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
