DA-70868 | DIGITUS
14 inch Universal Docking Station, USB Type-C, DA-70868
NCNR (non cancelable / non returnable)
Universal notebook docking station, DA-70868, DIGITUS
The 14" docking station extends your notebook by 14 extra ports via one USB-C connection. It contains, inter alia, three video ports (HDMI, DisplayPort, VGA) for connecting monitors, projectors, TVs, etc. Thanks to triple monitor support, these can be used simultaneously. Under Windows, a video signal can be output simultaneously to three different video ports (SST mode); additionally, three different video signals can be output to three different graphics ports (MST mode).
The other interfaces offer connectivity to all common connections that a modern docking station should have. For example, a network connection, other USB connections (USB-C, USB-A), an audio output or two independent card readers. The integrated USB-C port with PD charging can charge your notebook whilst using the docking station. The docking station also offers various USB 3.0 and 2.0 ports for data transfer, connection to periphery devices such as mouses and keyboards and for charging mobile devices.
| Filter | Property | Value |
|---|---|---|
| Connection (1) | USB-C | |
| Connection (2) | 3 x USB 3.0/2 x USB/USB-C/HDMI/DP/VGA/RJ45/SD/microSD/Audio | |
| Data transmission rate | 5000000000 mb/s | |
| Length | 350 mm | |
| Width | 74 mm | |
| Height | 18 mm | |
| Colour | black |
| Property | Value |
|---|---|
| Customs tariff number | 84718000 |
| Country of origin | CN |
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
