ZPF000000000100306 | DEUTSCH
Pin header, 20 pole, pitch 2.54 mm, angled, black, ZPF000000000100306
Order No.: 37P4598
EAN: 4099889954913
MPN:
ZPF000000000100306
732-8256-22
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
64.6289 € *
Standard delivery time from the manufacturer is: 16 Weeks
Pin header, ZPF000000000100306, DEUTSCH
Socket, Contact Insert, 20 Pole Configuration, 5 A, Wire-to-Board, Sealable, Power, Signal & High Speed Data.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | pin header | |
| Contact type | socket | |
| Pin number | 20 pole | |
| Grid | 2.54 mm | |
| Connection | solder pin | |
| Orientation | angled | |
| Type of locking | Yes | |
| contact surface | gold-plated | |
| Rated voltage | 115 V | |
| Rated current | 5 A | |
| Additional parts | equipped | |
| Number of rows | 4 | |
| Colour | black |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85369095 |
| Country of origin | TW |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| RoHS conform | Yes |
| Substance description | Lead |
| Electrical equipment take-back |  |
