ZPF000000000015233 | DEUTSCH
Pin header, 8 pole, pitch 4.62 mm, straight, black, ZPF000000000015233
Order No.: 37P4571
EAN: 4099889954685
MPN:
ZPF000000000015233
DMC-M 08-16 PN
Unit Price (€ / pc.)
24.3236 € *
Standard delivery time from the manufacturer is: 8 Weeks
Male connector, ZPF000000000015233, TE Connectivity
Product Type: Module, Rectangular Connector Insert Type: Pin, Connector System: Wire-to-Wire, Sealable: Yes, Connector & Contact Terminates To: Wire & Cable, Number of Positions: 8, Module Material: Composite, Contact Type: Pin, Contact Insert Pole Configuration: 8, Contact Current Rating (Max): 13 A, Termination Method to Wire & Cable: Crimp, Connector Mounting Type: Cable Mount (Free-Hanging), Centerline (Pitch): 4.62 mm, Wire Size: 20 – 16 AWG, Wire Size: 0.61 – 1.21 mm², Operating Temperature Range: -55 – 175 °C, Circuit Application: Power, Signal & Data, Packaging Method: Package
Technical specifications
| Colour | black | |
| contact surface | gold-plated | |
| Rated current | 13 A | |
| Grid | 4.62 mm | |
| Pin number | 8 pole | |
| Version | pin header | |
| Additional parts | unequipped | |
| Orientation | straight | |
| Connection | crimp connection | |
| Contact type | pin | |
| Rated voltage | 125 V | |
| Number of rows | 3 |
Download
Logistics
| Country of origin | IN |
| Customs tariff number | 85389091 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| SVHC free | No |
| RoHS conform | Yes |
