ABC03N-20P-4048 | DEUTSCH
Socket header, 5 pole, straight, black, ABC03N-20P-4048
Order No.: 37P4222
EAN: 4099889954579
MPN:
ABC03N-20P-4048
Unit Price (€ / pc.)
98.7581 € *
Standard delivery time from the manufacturer is: 47 Weeks
PCB Connection System, ABC03N-20P-4048, Deutsch
Wire-to-Wire, Wire & Cable, 5 Position
Technical Data
- Connector Mounting Type: Fixing Screw
- Contact Type: Male
- Housing Material: Composite
- Number of positions: 5
- Operating Temperature Range: -65 – 175 °C [-85 – 347 °F]
- Rated current: 7.5 A
- Sealable: Yes
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated current | 7.5 A | |
| Version | socket header | |
| Number of rows | 2 | |
| Connection | crimp connection | |
| Contact type | pin | |
| Additional parts | unequipped | |
| Pin number | 5 pole | |
| Orientation | straight | |
| Type of locking | Yes | |
| Colour | black |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85389091 |
| Country of origin | US |
Compliance
| Property | Value |
|---|---|
| Substance description | Lead |
| SVHC free | No |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
