LR1200480D40 | CRYDOM
Solid state relay, 480 VAC, zero voltage switching, 4-32 VDC, 40 A, PCB mounting, LR1200480D40
Unit Price (€ / pc.)
90.7851 € *
Available in 5 Days: 174 pcs. - if ordered today
Total Price:
90.79 € *
Price list
Quantity
Price per unit*
1 pcs.
90.7851 €
2 pcs.
88.2623 €
5 pcs.
85.8704 €
*incl. VAT plus shipping costs
Subject to prior sale
Solid state relay, LR1200480D40, CRYDOM
Solid state relay, PCB Mount, 480VAC/40A, DC In, Zero Cross.
Features
- SIP SSR
- Ratings to 40A @ 600 VAC with external heat sink
- SCR output for heavy industrial loads
- AC or DC control
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated current | 40 A | |
| Voltage | 4-32 VDC | |
| Control Voltage | 480 VAC | |
| Voltage V RRM (peak reverse voltage) | 1.2 kV | |
| Switching Mode | zero voltage switching | |
| Assembly | PCB mounting | |
| LED display | No |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85364900 |
| Country of origin | MX |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
