H12WD4825PG | CRYDOM
Solid state relay, 660 VAC, zero voltage switching, 4-32 VDC, 25 A, PCB mounting, H12WD4825PG
Unit Price (€ / pc.)
107.4332 € *
Available in 5 Days: 13 pcs. - if ordered today
Solid state relay, H12WD4825PG, CRYDOM
Solid state relay, Panel Mount, IP00, 660VAC/25A, DC In, Zero Cross, IOP, LED.
Features
- Low off-state leakage current (snubberless)
- SCR output for heavy industrial loads
- UL/CSA/VDE Approved, CE Compliant to EN60950-1
- Improved SEMS screw and washer
- Redesigned housing with anti-rotation barriers
- DC control
- Direct Bond Copper substrate
- EMC Compliant to Level 3
- Direct Power Lead Frame
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated current | 25 A | |
| Voltage | 4-32 VDC | |
| Control Voltage | 660 VAC | |
| Voltage V RRM (peak reverse voltage) | 1.2 kV | |
| Switching Mode | zero voltage switching | |
| Assembly | PCB mounting | |
| LED display | Yes |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | MX |
| Customs tariff number | 85364900 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
