Solid state relay, ED24D3, CRYDOM
This AC Output Plug-in solid state relay offers substantial performance advantages over traditional EMR switching solutions in many applications. The ED24D3 has a SPST N.O. Zero Voltage Turn-On output rated for 3 Amps at 24 to 280 VAC, and it's UL 508 recognized, IEC rated and CE compliant.
Features
- Fits standard DIN rail and PCB mountable sockets
- LED input status indicator
- Horsepower rated, Pilot duty rated
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Control Voltage | 3-15 VDC | |
| Assembly | DIN rail | |
| LED display | Yes | |
| Switching Mode | zero voltage switching | |
| Rated current | 3 A |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | MX |
| Customs tariff number | 85364900 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
