CXE480D5 | CRYDOM
Solid state relay, 15-32 VDC, zero voltage switching, 48-660 VAC, 5 A, PCB mounting, CXE480D5
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
40.6980 € *
Available in 12 Days: 6 pcs. - if ordered today
Total Price:
40.70 € *
Price list
Quantity
Price per unit*
1 pcs.
40.6980 €
5 pcs.
38.9011 €
10 pcs.
37.2589 €
25 pcs.
35.7476 €
*incl. VAT plus shipping costs
Subject to prior sale
Solid state relay, CXE480D5, CRYDOM
The CXE480D5 has a SCR output with 5 Amps @ 660 VAC ratings and a high surge current capability in a small package. Available with a DC input and Zero Voltage Turn-On output, it is suitable for a very broad range of applications such as: heating control, motor switching, lighting control, vending machines, medical equipment, HVAC and appliances among many others.
Features
- Standard SIP package
- Back-to-back SCR output for heavy industrial loads
- UL, CSA and VDE certified, CE compliant to EN60950-1
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated current | 5 A | |
| Voltage | 48-660 VAC | |
| Control Voltage | 15-32 VDC | |
| Voltage V RRM (peak reverse voltage) | 1.2 kV | |
| Switching Mode | zero voltage switching | |
| Assembly | PCB mounting | |
| LED display | No |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | MX |
| Customs tariff number | 85364900 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
