CWA2425-10 | CRYDOM
Solid state relay, 280 VAC, immediate switching, 90-280 VAC, 25 A, PCB mounting, CWA2425-10
Unit Price (€ / pc.)
91.4991 € *
Available in 5 Days: 19 pcs. - if ordered today
Total Price:
183.00 € *
Price list
Quantity
Price per unit*
2 pcs.
91.4991 €
6 pcs.
88.2028 €
13 pcs.
85.8228 €
20 pcs.
84.0021 €
*incl. VAT plus shipping costs
Subject to prior sale
Solid state relay, CWA2425-10, CRYDOM
This Panel mount AC output solid state relays offers a back-to-back SCR output for reliable switching of commercial and heavy industrial loads. It includes a removable IP20 “touch-safe” cover for added safety.
Features
- LED status indicator
- UL/CSA/TUV Approved, CE Compliant to EN60950-1
- Improved SEMS screw and washer
- Redesigned housing with anti-rotation barriers
- EMC Compliant to Level 3
- Epoxy free design
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated current | 25 A | |
| Voltage | 90-280 VAC | |
| Control Voltage | 280 VAC | |
| Voltage V RRM (peak reverse voltage) | 600 V | |
| Switching Mode | immediate switching | |
| Assembly | PCB mounting | |
| LED display | Yes |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | MX |
| Customs tariff number | 85364900 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
