84134010 | CRYDOM
Solid state relay, 280 VAC, zero voltage switching, 3-32 VDC, 25 A, PCB mounting, 84134010
Unit Price (€ / pc.)
84.7637 € *
Available in 5 Days: 647 pcs. - if ordered today
Total Price:
169.53 € *
Price list
Quantity
Price per unit*
2 pcs.
84.7637 €
7 pcs.
81.2056 €
14 pcs.
79.1707 €
20 pcs.
77.4690 €
*incl. VAT plus shipping costs
Subject to prior sale
Solid state relay, 84134010, CRYDOM
Solid state relay, Panel Mount, IP00, 280VAC/25A, DC In, Zero Cross.
Features
- LED Input Status Indicator
- UL Approved, CE Compliant to EN60950-1
- Improved SEMS screw and washer
- Redesigned housing with anti-rotation barriers
- EMC Compliant to level 3
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated current | 25 A | |
| Voltage | 3-32 VDC | |
| Control Voltage | 280 VAC | |
| Voltage V RRM (peak reverse voltage) | 600 V | |
| Switching Mode | zero voltage switching | |
| Assembly | PCB mounting | |
| LED display | Yes |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | MX |
| Customs tariff number | 85364900 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
