6STD37SAM99B50XE | CONEC
D-Sub socket, 37 pole, standard, equipped, straight, solder cup, 6STD37SAM99B50XE
Order No.: 74F600
EAN: 4099889809572
MPN:
6STD37SAM99B50XE
Unit Price (€ / pc.)
31.3684 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
31.37 € *
Price list
Quantity
Price per unit*
1 pcs.
31.3684 €
2 pcs.
29.3454 €
5 pcs.
27.5723 €
10 pcs.
25.6326 €
*incl. VAT plus shipping costs
Subject to prior sale
D-Sub socket, 6STD37SAM99B50XE, CONEC
Features
- Metal shell: Copper alloy
- Contact material: Copper alloy
- With O-ring
- With threaded lock and hexlocking screw
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | socket header | |
| Pin number | 37 pole | |
| Type of locking | threaded bolts 4-40 UNC | |
| Contact connection | solder cup | |
| Attachment (rear panel) | spacer bolt 4-40 UNC | |
| Additional parts | equipped | |
| Pole image | standard | |
| Assembly | straight |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
