6STD25SAM99B50XE | CONEC
D-Sub socket, 25 pole, high density, equipped, straight, solder cup, 6STD25SAM99B50XE
Order No.: 74F597
EAN: 4099889809558
MPN:
6STD25SAM99B50XE
Unit Price (€ / pc.)
23.9190 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
23.92 € *
Price list
Quantity
Price per unit*
1 pcs.
23.9190 €
2 pcs.
22.3839 €
5 pcs.
21.0273 €
10 pcs.
19.5398 €
*incl. VAT plus shipping costs
Subject to prior sale
D-Sub socket, 6STD25SAM99B50XE, CONEC
Features
- Metal shell: Copper alloy
- Contact material: Copper alloy
- With O-ring
- With threaded lock and hexlocking screw
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Additional parts | equipped | |
| Pin number | 25 pole | |
| Pole image | high density | |
| Type of locking | threaded bolts 4-40 UNC | |
| Attachment (rear panel) | spacer bolt 4-40 UNC | |
| Assembly | straight | |
| Contact connection | solder cup | |
| Version | socket header |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
