164A16579X | CONEC
D-Sub socket, 15 pole, standard, equipped, straight, solder pin, 164A16579X
Order No.: 74F324
EAN: 4099889808957
MPN:
164A16579X
Unit Price (€ / pc.)
5.7953 € *
Standard delivery time from the manufacturer is: 7 Weeks
Total Price:
5.80 € *
Price list
Quantity
Price per unit*
1 pcs.
5.7953 €
10 pcs.
5.3788 €
25 pcs.
5.0218 €
50 pcs.
4.5577 €
*incl. VAT plus shipping costs
Subject to prior sale
Socket Header, 164A16579X, CONEC
D-Sub, standard, Socket strip, 15-pole, Solder pin, Operating temperature -55 to 125°C, dielectric strength signal 1000 V, protection class IP20
Technical Data
- Assembly: PCB, straight
- Pin number: 15-pole
- Pole image: Standard
- Additional parts: Fully equipped
- Contact connection: Solder pin
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Additional parts | equipped | |
| Contact connection | solder pin | |
| Pin number | 15 pole | |
| Type of locking | threaded bolts 4-40 UNC | |
| Version | socket header | |
| Assembly | straight | |
| Attachment (rear panel) | spacer bolt with Snap-In | |
| Pole image | standard |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
