19090355 | CML
Signal light, 24 V (AC), 24 V (DC), green, 1.3 cd, Mounting Ø 8 mm, LED number: 1, 19090355
Unit Price (€ / pc.)
18.4212 € *
Next delivery: 33 pcs. on 2025-11-21
Total Price:
18.42 € *
Price list
Quantity
Price per unit*
1 pcs.
18.4212 €
10 pcs.
16.2078 €
50 pcs.
15.1130 €
150 pcs.
14.4466 €
500 pcs.
13.7088 €
*incl. VAT plus shipping costs
Subject to prior sale
LED signal lamps, type CML 1909.
Panel-mount diameter: 8.0 mm, Very bright light source, visible in sunlight. LED diameter: 5.0 mm, inner reflector made of high-gloss chrome-plated brass, series resistor and half-wave rectifier. Connection: tab terminals 2.8 x 0.8 mm. Degree of protection (EN 60529): IP 67, at the front between the LED and housing, and between the housing and front panel if the included seal ring is used. Ambient temperatures: –20 to +60 °C.
Technical attributes (type, rated voltage, color, rated current (AC/DC), luminous intensity): 19090355, 24 V AC/DC, green, 9.0/17 mA, 1300 mcd
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Diode Diameter | 5 mm | |
| Rated voltage (DC) | 24 V | |
| Installation diameter | 8 mm | |
| Connection | faston plug 2.8 x 0.8 mm | |
| Rated current | 17 mA | |
| Number of LEDs | 1 | |
| Farbe der Beleuchtung | green | |
| Assembly | central Mounting | |
| Luminous intensity | 1.3 cd | |
| Rated voltage (AC) | 24 V |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85414100 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| RoHS conform | Yes |
| Substance description | Lead |
