45305 | CM Manufactory
Safety relays, 2 Form A (N/O) + 1 Form B (N/C) + 1 PLC output, 24 V AC/DC, 45305
Unit Price (€ / pc.)
217.1988 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
217.20 € *
Price list
Quantity
Price per unit*
1 pcs.
217.1988 €
5 pcs.
187.3834 €
10 pcs.
157.5679 €
*incl. VAT plus shipping costs
Subject to prior sale
Safety controller, 45305, CM Manufactory
The 45305 is a switching device for two-hand switches according to DIN EN ISO 13851, ZH1/456 and DIN EN 574 up to requirement class III c.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | safety switching device | |
| Contact type | 2 Form A (N/O) + 1 Form B (N/C) + 1 PLC output | |
| Input voltage AC | 24 V AC/DC | |
| Type of Use | for two-hand controls | |
| Assembly | DIN rail | |
| Width | 22.5 mm | |
| Height | 99 mm | |
| Depth | 114.5 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85364190 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| SVHC free | No |
| RoHS conform | Yes |
