HHXJ250ARA471MJA0G | Chemi-Con
Polymer hybrid aluminum electrolytic capacitor, SMD, 470 µF, 25 V, ±20 %, HHXJ250ARA471MJA0G
Unit Price (€ / pc.)
2.3205 € *
Available: 47 pcs.
Total Price:
2.32 € *
Price list
Quantity
Price per unit*
1 pcs.
2.3205 €
10 pcs.
1.4994 €
100 pcs.
1.1543 €
500 pcs.
0.9163 €
1000 pcs.
0.8330 €
*incl. VAT plus shipping costs
Subject to prior sale
Conductive polymer hybrid, HHXJ250ARA471MJA0G, Chemi-Con
The HHXJ250ARA471MJA0G is a conductive polymer hybrid aluminum electrolytic capacitor with high reliability realized by hybrid electrolyte.
For high temperature and high reliability applications like automotive equipment, base station equipment, etc.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Capacity | 470 µF | |
| diameter | 10 mm | |
| max. operating temperature | 125 °C | |
| Length | 10 mm | |
| min. operating temperature | -55 °C | |
| Ripple current | 2.8 A | |
| Design | SMD | |
| ESR (Equivalent Series Resistance) | 20 mΩ | |
| Rated voltage (DC) | 25 V | |
| Tolerance | ±20 % |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85322200 |
| Original Packaging | Reel with 500 pieces |
| Country of origin | JP |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
