HHXC630ARA220MF80G | Chemi-Con
Polymer hybrid aluminum electrolytic capacitor, SMD, 22 µF, 63 V, ±20 %, HHXC630ARA220MF80G
Unit Price (€ / pc.)
1.0353 € *
Available: 50 pcs.
Total Price:
1.04 € *
Price list
Quantity
Price per unit*
1 pcs.
1.0353 €
10 pcs.
0.6664 €
100 pcs.
0.5117 €
500 pcs.
0.4165 €
900 pcs.
0.3808 €
*incl. VAT plus shipping costs
Subject to prior sale
Conductive polymer hybrid, HHXC630ARA220MF80G, Chemi-Con
The HHXC630ARA220MF80G is a conductive polymer hybrid aluminum electrolytic capacitor with high reliability and high voltage realized by hybrid electrolyte.
For high temperature and high reliability applications like automotive equipment, base station equipment, etc.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| ESR (Equivalent Series Resistance) | 80 mΩ | |
| Ripple current | 900 mA | |
| Length | 7.7 mm | |
| max. operating temperature | 125 °C | |
| diameter | 6.3 mm | |
| Capacity | 22 µF | |
| Rated voltage (DC) | 63 V | |
| Tolerance | ±20 % | |
| min. operating temperature | -55 °C | |
| Design | SMD |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Reel with 900 pieces |
| Country of origin | JP |
| Customs tariff number | 85322200 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
