SOL965460 | Celduc Relais
Solid state relay, 3.5-32 VDC, zero voltage switching, 24-600 VAC, 50 A, screw mounting, SOL965460
Order No.: 45P4917
EAN: 3760283300040
MPN:
SOL965460
Unit Price (€ / pc.)
48.195 € *
Available in 5 Days: 21 pcs. - if ordered today
Solid state relay, SOL965460, Celduc Relais
The SOL965460 is a single phase power solid state relay designed for resistive loads (AC-51).
Features
- Green LED visualization on the input
- Input over-voltage protection
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated current | 50 A | |
| Voltage | 24-600 VAC | |
| Control Voltage | 3.5-32 VDC | |
| Switching Mode | zero voltage switching | |
| Assembly | screw mounting | |
| LED display | Yes |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | FR |
| Customs tariff number | 85365003 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
