SKB10420 | Celduc Relais

Solid state relay, 3-10 VDC, zero voltage switching, 12-280 VAC, 5 A, PCB mounting, SKB10420

Order No.: 45P4760
EAN: 3760283308237
MPN:
SKB10420
SKB10420 Celduc Relais Solid State Relays
Image may differ
Unit Price (€ / pc.)
19.992 € *
Standard delivery time from the manufacturer is: 9 Weeks
Total Price:
1,999.20 € *
*incl. VAT plus shipping costs
Subject to prior sale
100 pcs.
19.992 €

Solid state relay, SKB10420, Celduc Relais

The SKB10420 is a AC Solid state relay for printed circuit board mounting and is designed for resistive loads, lamps or inductive loads with external VDR.

Features

  • Very low zero cross voltage
  • High surge current with a nominal power component of 10A
Technical specifications
Filter Property Value
Rated current 5 A
Voltage 12-280 VAC
Control Voltage 3-10 VDC
Voltage V RRM (peak reverse voltage) 600 V
Switching Mode zero voltage switching
Assembly PCB mounting
LED display No
Logistics
Property Value
Country of origin FR
Customs tariff number 85365003
Compliance
Property Value
SVHC free Yes
Date of RoHS guidelines 3/31/15
RoHS conform Yes
