SG464020 | Celduc Relais
Solid state relay, 0-10 VDC, 200-460 VAC, 40 A, screw mounting, SG464020
Order No.: 45P4694
EAN: 3760283306035
MPN:
SG464020
Unit Price (€ / pc.)
350.693 € *
Standard delivery time from the manufacturer is: 7 Weeks
Phase angle controller, SG464020, Celduc Relais
The SG464020 is a relay with proportional control that has an analog input isolated from the mains, provided to vary the phase angle proportionally to the input and so the voltage on the load.
Applications
- Lighting regulation
- Single phase motors
- Heating regulation
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Assembly | screw mounting | |
| Voltage V RRM (peak reverse voltage) | 1200 V | |
| Voltage | 200-460 VAC | |
| Rated current | 40 A | |
| Control Voltage | 0-10 VDC | |
| LED display | No |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | FR |
| Customs tariff number | 85365003 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
