PTB10030 | Celduc Relais
Proximity switch, plastic, 1 Form C (NO/NC), 60 W, 300 V (DC), 1 A, PTB10030
Unit Price (€ / pc.)
59.50 € *
Standard delivery time from the manufacturer is: 15 Weeks
Magnetic proximity sensor, PTB10030, Celduc Relais
Magnetic proximity sensor with REED switch and 1 normally closed contact.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| switching current | 1 A | |
| Latching switching function | 1 Form C (NO/NC) | |
| Breaking capacity | 60 W | |
| Degree of protection (IP) | IP67 | |
| Connection | cable connection | |
| Detecting distance | 8-20 mm | |
| Version | plastic | |
| Product type | proximity sensor | |
| diameter | 8 mm | |
| Contact resistance | 200 mΩ | |
| Switching Voltage (DC) | 300 V | |
| Length | 36.8 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | FR |
| Customs tariff number | 85365080 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
