PSC41000 | Celduc Relais
Proximity switch, plastic, built-in mounting, 1 Form C (NO/NC), 100 W, 350 V (DC), 3 A, PSC41000
Order No.: 45P4578
EAN: 3760283304826
MPN:
PSC41000
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
65.9498 € *
Available in 5 Days: 17 pcs. - if ordered today
Magnetic proximity sensor, PSC41000, Celduc Relais
Magnetic proximity sensor with contact changeover.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Product type | proximity sensor | |
| Version | plastic | |
| Latching switching function | 1 Form C (NO/NC) | |
| Breaking capacity | 100 W | |
| Switching Voltage (DC) | 350 V | |
| Switching Voltage (AC) | 300 V | |
| switching current | 3 A | |
| Detecting distance | 8 mm | |
| Assembly | built-in mounting | |
| Connection | cable connection 0.4 m | |
| Degree of protection (IP) | IP67 | |
| Length | 51 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | FR |
| Customs tariff number | 85365080 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
