PSA60020 | Celduc Relais
Proximity switch, plastic, screw mounting, 1 Form A (N/O), 800 W, 2 A, PSA60020
Unit Price (€ / pc.)
78.9922 € *
Standard delivery time from the manufacturer is: 7 Weeks
Magnetic safety sensor, PSA60020, Celduc Relais
The PSA60020 is a magnetic safety sensor without coding has been designed to meet the security requirements for machines presenting "low danger". With an output power up to 2A 440VAC with integrated voltage protection, this sensors can directly drive a power contactor.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | plastic | |
| switching current | 2 A | |
| Latching switching function | 1 Form A (N/O) | |
| Degree of protection (IP) | IP67 | |
| Switching Voltage (AC) | 440 V | |
| Breaking capacity | 800 W | |
| Detecting distance | 12 mm | |
| Length | 51 mm | |
| Connection | stranded wires | |
| Product type | proximity sensor | |
| Assembly | screw mounting |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85365080 |
| Country of origin | FR |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
