PS2A0020 | Celduc Relais
Magnet sensor, plastic, built-in mounting, 2 Form A (N/O), 10 W, 100 V (DC), 0.5 A, PS2A0020
Order No.: 45P4574
EAN: 3760283304864
MPN:
PS2A0020
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
68.9129 € *
Available in 5 Days: 24 pcs. - if ordered today
Magnetic proximity sensor, PS2A0020, Celduc Relais
Magnetic proximity sensor with REED switch and 2 normally open contacts.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Product type | magnet sensor | |
| Version | plastic | |
| Latching switching function | 2 Form A (N/O) | |
| Breaking capacity | 10 W | |
| Switching Voltage (DC) | 100 V | |
| Switching Voltage (AC) | 48 V | |
| switching current | 0.5 A | |
| Detecting distance | 15-25 mm | |
| Assembly | built-in mounting | |
| Connection | cable connection 2 m | |
| Degree of protection (IP) | IP67 | |
| Length | 51 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | FR |
| Customs tariff number | 85365080 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
