PMG13051 | Celduc Relais
Proximity switch, plastic, built-in mounting M14, 1 Form C (NO/NC), 30 W, 230 V (DC), 0.5 A, PMG13051
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
47.5048 € *
Standard delivery time from the manufacturer is: 15 Weeks
Magnetic proximity sensor, PMG13051, Celduc Relais
Magnetic proximity sensor with 1 normally closed contact.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Product type | proximity sensor | |
| Version | plastic | |
| Latching switching function | 1 Form C (NO/NC) | |
| Breaking capacity | 30 W | |
| Switching Voltage (DC) | 230 V | |
| Switching Voltage (AC) | 110 V | |
| switching current | 0.5 A | |
| Contact resistance | 120 mΩ | |
| Detecting distance | 17-27 mm | |
| Assembly | built-in mounting M14 | |
| Connection | cable connection | |
| Degree of protection (IP) | IP65 | |
| diameter | 9 mm | |
| Length | 60 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85365080 |
| Country of origin | FR |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
