PLB1179EX | Celduc Relais
Magnet sensor, plastic, built-in mounting, 1 Form B (N/C), 10 W, 60 V (DC), 0.4 A, PLB1179EX
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
115.4895 € *
Available in 5 Days: 37 pcs. - if ordered today
Magnetic proximity sensor, PLB1179EX, Celduc Relais
Magnetic proximity sensor with 1 Form B (N/C).
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Product type | magnet sensor | |
| Version | plastic | |
| Latching switching function | 1 Form B (N/C) | |
| Breaking capacity | 10 W | |
| Switching Voltage (DC) | 60 V | |
| switching current | 0.4 A | |
| Detecting distance | 15-40 mm | |
| Assembly | built-in mounting | |
| Connection | cable connection 10 m | |
| Degree of protection (IP) | IP67 | |
| Length | 32 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | FR |
| Customs tariff number | 85365080 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
