BD132 | CDIL
Bipolar junction transistor, PNP, 3 A, 45 V, THT, TO-126, BD132
Order No.: 13S4300
MPN:
BD132
EAN: 4099879027931
Images may differ
Unit Price (€ / pc.)
0.9282 € *
Available: 4 pcs.
Leadtime: 4 Weeks **
Total Price:
0.93 € *
Quantity
Price per unit*
1 pcs.
0.9282 €
10 pcs.
0.8092 €
50 pcs.
0.7140 €
*incl. VAT plus shipping costs
**Subject to prior sale
Description
Transistors series BD.
Technical attributes (type, package, manufacturer): BD132, TO126
Technical specifications
| Version | PNP | |
| Enclosure | TO-126 | |
| max. operating temperature | 150 °C | |
| max.voltage between collector and base Vcbo | 45 V | |
| max.voltage between collector and emitter Vceo | 45 V | |
| min. operating temperature | -65 °C | |
| Assembly | THT | |
| Rated current | 3 A | |
| Saturation voltage | 700 mV | |
| Transit frequency fTmin | 60 MHz | |
| Power dissipation | 15 W | |
| Collector current | 3 A | |
| Min DC gain | 20 mA |
Download
Logistics
| Country of origin | IN |
| Customs tariff number | 85412900 |
| Original Packaging | Bulk with 500 pieces |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
