EC5525PPAP | Carlo Gavazzi
Capacitive sensor, PNP, flush mounting, not flush, 1 Form A (N/O), 40 V (DC), 200 mA, EC5525PPAP
Unit Price (€ / pc.)
139.5394 € *
Standard delivery time from the manufacturer is: On Request
Proximity sensor capacitive, EC5525PPAP, Carlo Gavazzi
Capacitive proximity switch with sensing distance 16 mm flush mounted and sensing distance 25 mm nonflush mounted by adjustment. 4-wire DC output with both make (NO) and break (NC) switching. Flat pack housing, size (WxHxD) 35 x 55 x 15 mm made in polycarbonate. Easy mounting with only two M4 screws. Ideal for use in material handling and plastic machinery applications.
Features
- Make and break switching function, LED indication
- High noise immunity
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Switching Voltage (DC) | 40 V | |
| Connection | M12-connector | |
| Degree of protection (IP) | IP67 | |
| Latching switching function | 1 Form A (N/O) | |
| switching current | 200 mA | |
| Assembly | flush mounting, not flush | |
| Detecting distance | 25 mm | |
| Version | PNP | |
| Product type | capacitive sensor | |
| Length | 55 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85365080 |
| Country of origin | LT |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
