EC5525PPAP-1 | Carlo Gavazzi
Capacitive sensor, PNP, Surface mounting, 1 Form A (N/O), 40 V (DC), 200 mA, EC5525PPAP-1
Unit Price (€ / pc.)
157.0562 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
157.06 € *
Price list
Quantity
Price per unit*
1 pcs.
157.0562 €
3 pcs.
152.3319 €
10 pcs.
147.0959 €
25 pcs.
143.1689 €
*incl. VAT plus shipping costs
Subject to prior sale
Proximity sensor capacitive, EC5525PPAP-1, Carlo Gavazzi
Capacitive proximity switch with sensing distance 16 mm flush mounted and sensing distance 25 mm nonflush mounted by adjustment. 4-wire DC output with both make (NO) and break (NC) switching. Flat pack housing, size (WxHxD) 35 x 55 x 15 mm made in polycarbonate. Easy mounting with only two M4 screws. Ideal for use in material handling and plastic machinery applications.
Features
- Make and break switching function, LED indication
- High noise immunity
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Switching Voltage (DC) | 40 V | |
| Connection | M12-connector | |
| Degree of protection (IP) | IP67 | |
| Latching switching function | 1 Form A (N/O) | |
| switching current | 200 mA | |
| Assembly | Surface mounting | |
| Detecting distance | 25 mm | |
| Version | PNP | |
| Product type | capacitive sensor | |
| Length | 55 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85365080 |
| Country of origin | LT |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
