BYB-5-95F238 | by.B
Telephone cable, 8-wire, 8 x 0.14 mm², black, PVC, BYB-5-95F238
Order No.: 95F238
EAN: 4099891267650
MPN:
BYB-5-95F238
Unit Price (€ / mtr.)
1.6184 € *
Standard delivery time from the manufacturer is: 8 Weeks
Telecommunication cables, flat-oval, type FBL-9Y-Y 8X0,14.
D-shape according to DIN 47467 part 7, suitable for Western plug penetration technique.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | black | |
| Core colour sequence | DIN 47100 | |
| Core insulation material | PP | |
| Cable structure | 8 x 0.14 mm² | |
| Cable cross-section | 0.14 mm² | |
| Width | 7.9 mm | |
| Temperature range (unmoved) | -30 °C to 65 °C | |
| Number of cores | 8 | |
| Height | 2.3 mm | |
| Material | PVC | |
| Cable material | copper, bright |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444920 |
| Country of origin | DE |
| Original Packaging | Ring with 100 meters |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
