120307E39 | Bungard
Printed circuit board, positive photo-coated, 150 x 250 mm, single sided, FR4 epoxy, Cu 70 µm, 120307E39
 Order No.: 12H1470
  EAN: 4099889463705
  MPN:
  120307E39
 Unit Price (€ / pc.)
   9.0321 €  *
   Available: 12 pcs.
 Total Price:
  9.03 € *
  Price list
 Quantity
 Price per unit*
 1 pcs.
 9.0321 €
 10 pcs.
 7.9492 €
 50 pcs.
 7.4018 €
 150 pcs.
 7.0805 €
 500 pcs.
 6.7235 €
  *incl. VAT plus shipping costs
  Subject to prior sale
 Printed circuit board, 120307E39, Bungard
Substrate: FR 4, single-sided copper plating, 0.5 µm photo resist layer
Inflammability to: UL 94 V-0
Tested/released to: UL, NEMA, MIL, DIN, IEC
Material thickness: 1.5 mm
Copper plating: 70 µm
Format: 150 x 250 mm.
 Technical specifications

 | Filter | Property | Value |
|---|---|---|
| Height | 1.5 mm | |
| Material | FR4 epoxy | |
| Throughplated | No | |
| Length | 150 mm | |
| Width | 250 mm | |
| One / two-sided | single sided | |
| copper strength | 70 m | |
| Version | printed circuit board, positive photo-coated |
 Download
  Logistics

 | Property | Value |
|---|---|
| Customs tariff number | 37019900 |
| Country of origin | DE |
 Compliance

 | Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
