PXMBNI08FPM04AFL001 | BULGIN
Plug, M8, 4 pole, screw locking, straight, PXMBNI08FPM04AFL001
Unit Price (€ / pc.)
39.6151 € *
Available in 5 Days: 136 pcs. - if ordered today
Total Price:
39.62 € *
Price list
Quantity
Price per unit*
1 pcs.
39.6151 €
10 pcs.
37.2351 €
25 pcs.
34.6290 €
50 pcs.
31.8563 €
*incl. VAT plus shipping costs
Subject to prior sale
Sensor-actuator connector, PXMBNI08FPM04AFL001, BULGIN
Features
- Flying lead
- A-coded
- Compliant with EN 61076-2-104
- Degree of protection: IP67
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Pin number | 4 pole | |
| Degree of protection (IP) | IP67 | |
| Assembly | front mounting | |
| Additional parts | equipped | |
| Coding | A | |
| contact surface | gold-plated | |
| Orientation | straight | |
| Type of locking | screw locking | |
| Thread size | M8 | |
| Product type | plug |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Substance description | Lead |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
