PXP7012/32S/CR | BULGIN
Panel plug, 32 pole, crimp connection, screw locking, straight, PXP7012/32S/CR
Unit Price (€ / pc.)
9.9603 € *
Standard delivery time from the manufacturer is: 18 Weeks
Flex cable connectors series Buccaneer 7000, type Bulgin PXP70..
Front panel mount connectors, socket contacts, type PXP7012..
operating voltage: 600 V.
Operating current: 25 A.
Contact resistance: max. 10 Mohm.
Material: PC/PBT, halogen-free.
Inflammability class: UL 94 V-0.
Contacts: nickel-plated brass.
Degree of protection mated state: IP 66, IP 68, IP 69K.
Certifications: UL, cULus, VDE, CCC.
Operating temperatures: - 40 to +120 °C.
Table index: type, number of poles, contact gender, cable diameter, color.
PXP7012/32S/CR, 32-pole, crimp termination
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Additional parts | unequipped | |
| Type of locking | screw locking | |
| Version | panel plug | |
| Contact connection | crimp connection | |
| Pin number | 32 pole | |
| Assembly | PCB mounting | |
| Shell Material | PBT | |
| Orientation | straight |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | TN |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
