PXP7012/03S/ST | BULGIN
Panel plug, 3 pole, screw connection, screw locking, straight, PXP7012/03S/ST
Unit Price (€ / pc.)
33.3438 € *
Available in 5 Days: 20 pcs. - if ordered today
Total Price:
33.34 € *
Price list
Quantity
Price per unit*
1 pcs.
33.3438 €
10 pcs.
30.9638 €
25 pcs.
28.8932 €
50 pcs.
26.2752 €
*incl. VAT plus shipping costs
Subject to prior sale
Flex cable connectors series Buccaneer 7000, type Bulgin PXP70..
Front panel mount connectors, socket contacts, type PXP7012..
operating voltage: 600 V.
Operating current: 25 A.
Contact resistance: max. 10 Mohm.
Material: PC/PBT, halogen-free.
Inflammability class: UL 94 V-0.
Contacts: nickel-plated brass.
Degree of protection mated state: IP 66, IP 68, IP 69K.
Certifications: UL, cULus, VDE, CCC.
Operating temperatures: - 40 to +120 °C.
Table index: type, number of poles, contact gender, cable diameter, color.
PXP7012/03S/ST, 3-pole, screw termination
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Assembly | PCB mounting | |
| Type of locking | screw locking | |
| contact surface | nickel-plated | |
| Version | panel plug | |
| Additional parts | unequipped | |
| Pin number | 3 pole | |
| Contact connection | screw connection | |
| Orientation | straight | |
| Shell Material | brass |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | TN |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| SVHC free | No |
| RoHS conform | Yes |
