PXP7012/02P/ST | BULGIN
Panel plug, 2 pole, screw connection, screw locking, straight, PXP7012/02P/ST
Unit Price (€ / pc.)
20.6227 € *
Available in 5 Days: 70 pcs. - if ordered today
Total Price:
206.23 € *
Price list
Quantity
Price per unit*
10 pcs.
20.6227 €
20 pcs.
14.0420 €
*incl. VAT plus shipping costs
Subject to prior sale
Flex cable connectors series Buccaneer 7000, type Bulgin PXP70..
Front panel mount connectors, pin contacts, type PXP7012..
operating voltage: 600 V.
Operating current: 25 A.
Contact resistance: max. 10 Mohm.
Material: PC/PBT, halogen-free.
Inflammability class: UL 94 V-0.
Contacts: nickel-plated brass.
Degree of protection mated state: IP 66, IP 68, IP 69K.
Certifications: UL, cULus, VDE, CCC.
Operating temperatures: - 40 to +120 °C.
Table index: type, number of poles, contact gender, cable diameter, color.
PXP7012/02P/ST, 2-pole, screw termination
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Pin number | 2 pole | |
| Additional parts | unequipped | |
| Shell Material | brass | |
| Version | panel plug | |
| Assembly | PCB mounting | |
| Type of locking | screw locking | |
| contact surface | nickel-plated | |
| Orientation | straight | |
| Contact connection | screw connection |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | TN |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
