PX0941/10/S | BULGIN
Panel socket, 10 pole, screw connection, screw locking, straight, PX0941/10/S
Unit Price (€ / pc.)
72.7804 € *
Available in 5 Days: 34 pcs. - if ordered today
Circular connector series 900, type Bulgin PX09.
With screw terminals; Contact resistance: max. 10 mohm. Material: polyamide to UL 94 V-0. Contacts: nickel-plated brass. Degree of protection: IP 68. Operating temperatures: –40 to +85 °C. Certifications: CSA (rated current 25 to 30 A), UL, VDE, CCC (rated current 10 to 32 A).
Connectors, flange mount, female contacts, type PX0941.
Technical attributes (type, number of poles, rated voltage/current): PX0941/10/S, 10-pole, 250 V AC/DC/10 A
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Contact connection | screw connection | |
| contact surface | nickel-plated | |
| Assembly | PCB mounting | |
| Version | flange socket | |
| Shell Material | PA | |
| Additional parts | equipped | |
| Type of locking | screw locking | |
| Orientation | straight | |
| Pin number | 10 pole |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | TN |
Compliance
| Property | Value |
|---|---|
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| Substance description | Lead |
