PX0728/S | BULGIN
Jack, 9 pole, crimp connection, screw locking, straight, PX0728/S
Unit Price (€ / pc.)
25.2161 € *
Available in 5 Days: 20 pcs. - if ordered today
Total Price:
25.22 € *
Price list
Quantity
Price per unit*
1 pcs.
25.2161 €
10 pcs.
23.4192 €
25 pcs.
21.8603 €
50 pcs.
19.8730 €
*incl. VAT plus shipping costs
Subject to prior sale
Coupling, PX0728/S, Bulgin
Inline cable connector
Features
- Mates with inline
- Screw locking ring
- Socket
- Leading earth on 3 contact connectors
- Standard cable acceptance
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | jack | |
| Cable cross-section | 0.12-0.21 mm² | |
| Pin number | 9 pole | |
| Orientation | straight | |
| Contact connection | crimp connection | |
| Type of locking | screw locking | |
| Cable diameter | 6 to 8 mm | |
| Assembly | cable assembly | |
| Additional parts | equipped | |
| contact surface | tin-plated | |
| Shell Material | PA |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | TN |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
