PX0410/12P/6065 | BULGIN
Plug, 12 pole, crimp connection, screw locking, straight, PX0410/12P/6065
Unit Price (€ / pc.)
12.3760 € *
Available in 5 Days: 278 pcs. - if ordered today
Total Price:
210.39 € *
Price list
Quantity
Price per unit*
17 pcs.
12.3760 €
50 pcs.
10.6743 €
*incl. VAT plus shipping costs
Subject to prior sale
Circular connector series 400, type Bulgin PX04.
With flexible cable connection; Contact resistance: max. 5.0 mohm. Material: polyamide to UL 94 V-0. Degree of protection: IP 68. Operating temperatures: –40 to +80 °C. Contacts are available on separate order.
Connector housings with male contact insert, type PX0410.
Technical attributes (type, number of poles, rated voltage/current, cable diameter): PX0410/12P/6065, 12-pole, 50 V AC/DC/1.0 A, 6.0 to 6.5 mm
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Cable diameter | 6 to 6.5 mm | |
| Additional parts | unequipped | |
| Type of locking | screw locking | |
| Version | plug | |
| Contact connection | crimp connection | |
| Pin number | 12 pole | |
| Assembly | cable assembly | |
| Shell Material | PA | |
| Orientation | straight |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | TN |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
