RFSMAA2JEGACDD | BULGIN

SMA flange socket 50 Ω, solder connection, straight, RFSMAA2JEGACDD

Order No.: 78F173
EAN: 4099891616878
MPN:
RFSMAA2JEGACDD
Series: SMA Series
RFSMAA2JEGACDD BULGIN Coaxial Connectors
Image may differ
Unit Price (€ / pc.)
44.6964 € *
Available in 5 Days: 25 pcs. - if ordered today
Total Price:
44.70 € *
Price list
Quantity
Price per unit*
1 pcs.
44.6964 €
10 pcs.
41.5072 €
25 pcs.
38.7345 €
50 pcs.
35.2121 €
*incl. VAT plus shipping costs
Subject to prior sale

SMA jack, RFSMAA2JEGACDD, BULGIN

This SMA connector is semi-precision with 0.25 - 36 threaded coupling. Offering high performance all within a compact SMA (Sub Miniature version A) connector design, frequently used as standard for antennas, devices and various medical applications. Moreover, this sub-miniature sizes is also used in relatively small items of electronic equipment. Typically, 500 mating cycles, but care is needed to keep the mating surfaces clean.

Features

  • Insulation resistance >5000 MOhm
  • 50-ohm impedance
  • Beryllium copper contact
Technical specifications
Filter Property Value
Contact connection solder connection
Design straight
Product type flange socket
Contact material beryllium copper
Connector SMA
Impedance 50 Ω
Logistics
Property Value
Country of origin CN
Compliance
Property Value
SVHC free Yes
Date of RoHS guidelines 3/31/15
RoHS conform Yes
