WS7A1001J | Bourns Electronics GmbH
Wirewound resistor, 1 kΩ, 7 W, ±5 %, WS7A1001J
Order No.: 07E8743
EAN: 4099879668264
MPN:
WS7A1001J
Unit Price (€ / pc.)
0.4046 € *
Standard delivery time from the manufacturer is: 19 Weeks
Wirewound resistor, WS7A1001J, Bourns Electronics GmbH
The WS7A1001J is a high surge withstand wirewound resistor with low thermal resistant ceramic core.
Applications
- Smart meters
- Renewable energy
- Industrial
- Power supplies/chargers
- Lighting
- Instruments/gauges
Technical specifications
| Filter | Property | Value |
|---|---|---|
| ohmic resistance | 1 kΩ | |
| Tolerance | ±5 % | |
| Power | 7 W | |
| Design | axial | |
| Assembly | THT | |
| Version | wirewound resistor | |
| Temperature coefficient | ±200 ppm/K | |
| min. operating temperature | -55 °C | |
| max. operating temperature | 200 °C | |
| diameter | 8.5 mm | |
| Length | 29.5 mm |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Ammopack with 500 pieces |
| Customs tariff number | 85332100 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
