PWR221T-30-12R0F | Bourns Electronics GmbH
Thick film resistor, 12 Ω, 30 W, ±1 %, PWR221T-30-12R0F
Order No.: 07E7064
EAN: 4099879667182
MPN:
PWR221T-30-12R0F
Unit Price (€ / pc.)
3.6414 € *
Standard delivery time from the manufacturer is: 12 Weeks
Power resistor, PWR221T-30-12R0F, Bourns Electronics GmbH
The PWR221T-30-12R0F is a TO-220 style power resistor made using thick film on alumina ceramic technology. It is used in current limiting, capacitor discharge or current measurement circuits in power supplies for telecom and industrial applications.
Features
- Low inductance
- Ceramic backplane
- High power rating
- RoHS compliant
Applications
- Power supplies
- Motor drives
- Test and measurement
- Rectifiers
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | thick film resistor | |
| min. operating temperature | -55 °C | |
| max. operating temperature | 150 °C | |
| Isolation voltage | 2 kV | |
| Height | 16.26 mm | |
| Tolerance | ±1 % | |
| Width | 3.18 mm | |
| ohmic resistance | 12 Ω | |
| Power | 30 W | |
| Length | 10.41 mm | |
| Temperature coefficient | ±100 ppm/K | |
| Design | radial | |
| Assembly | THT |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Bar with 50 pieces |
| MSL | MSL 1 |
| Customs tariff number | 85332900 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
