ISOM3-320-B-L2 | Bourns Electronics GmbH
Hybrid protection component, radial, 6000 A, 415 V (DC), 320 V (AC), ISOM3-320-B-L2
Unit Price (€ / pc.)
1.7493 € *
Available: 480 pcs.
Total Price:
17.49 € *
Price list
Quantity
Price per unit*
10 pcs.
1.7493 €
50 pcs.
1.5351 €
500 pcs.
1.2257 €
1000 pcs.
1.1424 €
2000 pcs.
1.0591 €
*incl. VAT plus shipping costs
Subject to prior sale
Varistor series IsoMOV
By combining the best features of both MOV and GDT technologies in a single component, the IsoMOV™ series achieves high performance with low capacitance, very low leakage current and excellent power handling density. The IsoMOV™ series is ideally suited for AC and DC power supply applications where highest performance and/or space savings are required.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage (AC) | 320 V | |
| Rated voltage (DC) | 415 V | |
| Design | radial | |
| max. Surge current, transient (8/20 µs) | 6000 A | |
| min. operating temperature | -40 °C | |
| Standard number | UL, CSA | |
| max. operating temperature | 125 °C | |
| Grid | 7.5 mm |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Bulk with 500 pieces |
| MSL | MSL 1 |
| Customs tariff number | 85334090 |
| Country of origin | CR |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
