TC33X-2-103E | Bourns Electronics GmbH
Cermet trimmer potentiometer, 10 kΩ, 0.1 W, SMD, on top, TC33X-2-103E
Unit Price (€ / pc.)
0.3689 € *
Available: 2,289 pcs.
Total Price:
3.69 € *
Price list
Quantity
Price per unit*
10 pcs.
0.3689 €
50 pcs.
0.2868 €
250 pcs.
0.2356 €
1000 pcs.
0.2083 €
2000 pcs.
0.1880 €
*incl. VAT plus shipping costs
Subject to prior sale
Trimmer potentiometer, TC33X-2-103E, Bourns
Features
- Recommended for reflow soldering
- 3 mm size meets EIA/EIAJ standard trimmer footprint
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Power | 0.1 W | |
| max. number of revolutions | 1 | |
| Seeting | on top | |
| Contact distance | RM 0.8 | |
| Connection | J-hook | |
| Temperature coefficient | ±250 ppm/K | |
| max. operating temperature | 100 °C | |
| Rotary range, electrical | 270 ° | |
| Tolerance | ±25 % | |
| Length | 3.8 mm | |
| Height | 1.2 mm | |
| Assembly | SMD | |
| Width | 3 mm | |
| min. operating temperature | -40 °C | |
| Track Taper | linear | |
| ohmic resistance | 10 kΩ | |
| Version | cermet trimmer potentiometer |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Original Packaging | Reel with 2,500 pieces |
| MSL | MSL 2 |
| Customs tariff number | 85334010 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
